DESCRIPTION

Basic Info.

Model NO.	SDT-10XU3Y60
Digital Noise Reduction	2D&3D Digital Noise Reduction
Optical Zoom	10X
Aperture	F1.5~F3.0
Exposure	Automatic/Manual
Blc	on/off
Focus	Auto/Manual/One-Key Focus;
White Balance	Uto/Manual/One-Touch White Balance
USB3.0 Output	Yuy2 1920*[email protected]; Mjpeg1920*[email protected]
USB2.0 Output	1920×[email protected];
Focal Length	4.34~35.17mm
Visual Angle	Horizontal Viewing Angle 8.8degree;~68.8degree
Image Sensor	1/2.8 Sony Sensor
Effective Pixels	2MP; 16:9
HDMI Output	[email protected]; [email protected];[email protected];
Transport Package	68*138*75mm
Specification	CE, FCC
Trademark	OEM
Origin	Shenzhen, China
HS Code	8525801390
Production Capacity	50, 000PCS/Year

Product Description

Product Description

1. Full HD images: USB3.0:YUY2 1080P60fps;HDMI:1080P60fps
2. Comes with USB serial port: USB2.0 interface comes with serial port, It can be set up and debugged using PC-side tools, It is convenient to set up the camera remotely, The PC tool can save configurations or import configurations with one click.
3. Image sensor: Using 1/2.8 inch high-quality image sensor, Deliver crisp and lifelike HD video, Vividly show the expressions and movements of the characters.
4. Optical zoom lens: It adopts 10x optical zoom and 68.8° wide-angle lens.
5. Multiple video interfaces: Support HDMI, USB 2.0, USB3.0 video output;
6. Autofocus technology: The advanced focusing algorithm is used to make the lens focus quickly, accurately and stably.
7. Portrait and horizontal screens: Support switching horizontal screen and vertical screen output mode with dip switch to better meet customers' playback needs for horizontal screen and vertical screen.
8. Professional graphic style: Support beauty and jewelry style modes to adjust the best image effect for live broadcast scenes.
9. Multiple video compression standards: The interface supports MJPEG, YUY2, and H.264 video compression formats.
10. Low noise and high signal-to-noise ratio: The low-noise CMOS effectively ensures the ultra-high signal-to-noise ratio of the camera video; Advanced 2D and 3D noise reduction technology is used to further reduce noise while ensuring image clarity.
11. Easy to use: No need to download the driver, the USB output is plug and play;

Product overview

Parameters/models	SDT-10XU3Y60
Camera, lens parameters
Image sensor	1/2.8 Sony sensor
Effective pixels	2MP; 16:9
Video signal	HDMI output supported video formats: [email protected]; [email protected]; [email protected]; [email protected]; [email protected]; [email protected]; USB2.0 output supports video formats: 1920×[email protected]; 1280×[email protected]; 1024×[email protected]; 960×[email protected]; 800×[email protected]; 640×[email protected]; 640×[email protected]; 320×176P30fps; USB3.0 output supports video formats: YUY2 1920×[email protected]; MJPEG1920×[email protected]
Visual angle	Horizontal viewing angle 8.8°~68.8°
Focal length	4.34~35.17mm
Aperture	F1.5~F3.0
Optical zoom	10X
Minimum illumination	0.1Lux(F1.8, AGC ON)
Digital noise reduction	2D&3D Digital noise reduction
Super automatic noise cancellation	On/off
White balance	Auto/manual/one-touch white balance /3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K
Focus	Auto/manual/one-key focus;
Exposure	Automatic/Manual
BLC	On/off
Signal to Noise Ratio	>50dB
Vertical screen switch	On/off
Minimum object distance	15cm(Far)~150cm(Near)
Interface functional performance
Video output interface	1 CH USB 2.0 interface: A type, Support video signal output; 1 CH USB 3.0 interface: A type, Support YUY2 format 60 frame video output, adaptive; 1 CH HDMI interface: Support video output
Video compression format	YUV, MJPG, H.264
Control interface	USB interface
Other parameters
Operating voltage	Power adapter	12V
	USB	5V
Operating current	Power adapter	0.425
	USB	1A(max)
Power consumption	5W(max)
Storage temperature	-10ºC~+60ºC
Storage humidity	20%~90%
Operating temperature	-10ºC~+50ºC
Operating humidity	20%~80%
Dimensions	68 mm×138 mm×75 mm
Weight	0.6kg
Usage environment	indoors
Annex	Instruction manual, USB 3.0 cable, power adapter, wireless remote control
